| Marketing Description |
| The growing number of connected personal and IoT devices has led to an overall increase in network density that is pushing the limits of the current Wi-Fi standard. The 802.11ax standard provides future-proof technologies, higher network efficiency, faster Wi-Fi speeds, greater coverage and improved battery life for connected devices, providing a significantly better networking experience for users. |
| Product Features |
- Next-Gen Wi-Fi speed
RT-AX55 is a 2x2 dual-band Wi-Fi router that provides 80MHz bandwidth and 1024-QAM for dramatically faster wireless connections. With a total networking speed of about 1800Mbps - 574Mbps on the 2.4GHz band and 1201Mbps on the 5GHz band - RT-AX55 is 1.5X faster than 802.11ac 2x2 dual-band routers. - Built for multi-device households
With a revolutionary combination of OFDMA and MU-MIMO technology, 802.11ax technology provides up to 4X greater network capacity and efficiency in traffic-dense environments. - Better battery life for your devices
Target Wake Time (TWT) allows RT-AX55 to schedule designated intervals for devices to transmit data. This allows them to sleep when there is no need to wait for a router signal, reducing power consumption by up to 7X for significantly improved battery life.
|
| General |
| Device Type | Wireless router - 4-port switch (integrated) |
| Enclosure Type | Desktop |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6) |
| Frequency Band | 2.4 GHz / 5 GHz |
| Network / Transport Protocol | PPTP, L2TP, NTP, IPSec, DHCP, DDNS |
| Routing Protocol | IGMPv2, IGMP, IGMPv3 |
| Encryption Algorithm | WPA-PSK, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise, WPA3-Personal |
| Features | IPv6 support, parental control, event log, Wi-Fi Protected Setup (WPS), static IP mode, DNS proxy, port forwarding, UPnP Media Server, port triggering, dynamic IP mode, MU-MIMO technology, beamforming technology, Adaptive QoS, Broadcom NitroQAM technology, VPN client, ASUS Router App, NTP client, Smart Connect, DMZ support, Traffic Analyser, ASUS AiMesh, ASUS AiProtection Classic, Bandwidth Limiter, L2TP client, PPTP client, IPSec server, PPTP server, OpenVPN client, Orthogonal Frequency Division Multiple Access (OFDMA), OpenVPN server, IPTV support |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, UPnP, IEEE 802.11ac, IEEE 802.11ax |
| Processor | 1 x 1.5 GHz |
| RAM | 256 MB |
| Flash Memory | 128 MB |
| Line Properties |
| Line Coding Format | 1024 QAM, OFDMA |
| Expansion / Connectivity |
| Interfaces | WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45
LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 |
| Aerial |
| Aerial | External |
| Antenna Qty | 4 |
| Power |
| Power Device | External power adapter |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Miscellaneous |
| Cables Included | 1 x network cable |
| Software / System Requirements |
| OS Required | Microsoft Windows 7, Apple MacOS X 10.6 or later, Android, Windows 8, Windows 10, Apple iOS 9 or later |
| Dimensions & Weight |
| Width | 23 cm |
| Depth | 13.4 cm |
| Height | 5.6 cm |
| Weight | 374 g |
